Small Tube Cutting Machine
Brand: HUOXIAN
Model:H-130
Type: pipe cutting machine
Description
The H-130 pipe cutting machine is a specialized equipment designed specifically for pipeline processing. It adopts advanced cutting technology and stable mechanical structure, which can achieve fast and precise cutting of various materials and pipes of different diameters. Whether it is cast iron, cast steel, structural steel, stainless steel, or alloy steel, H-130 can easily handle and meet various complex processing needs.
Essential information:
- Brand: HUOXIAN
- Model:H-130
- Type: pipe cutting machine
Product parameters
|
H-130 |
|
|
Cutting Capacity(mm) |
25(h) *100(w) |
|
Spindle speed(r/min) |
0-2000 |
|
Blade speeds(m/min) |
0-60 |
|
Motor Power(kw) |
1.1 |
|
Motor Speed(r/min) |
2500-2800 |
|
Input gas source(Mpa) |
0.5---0.8 |
|
Servo motor power(KW) |
0.75 |
|
Cooling motor power(KW) |
0.09 |
|
Inverter power(KW) |
1.5 |
|
Weight(kg) |
630 |
|
Machine Size(L*W*H)(mm) |
1850x100x1550 |
|
Cutting accuracy(mm) |
0.05 |
|
Maximum length (mm) |
210 |
Feature：
High cutting accuracy
HUOXIAN H-130 uses a 0.75kW absolute servo motor to drive each spindle, and cooperates with a dedicated closed-loop feedback encoder for full-range positioning to ensure that the axial movement error does not exceed ±0.05mm.
Multi-level frequency conversion speed regulation system
H-130 is equipped with a 1.5kW inverter to adjust the saw blade linear speed from 0-60m/min steplessly, and is equipped with a 0-2000rpm spindle speed control system to achieve matching cutting of different metal materials (such as stainless steel, copper tubes, and aluminum tubes).
Structural protection and lubrication system
The equipment uses a stainless steel chip cover to protect key moving parts, and cooperates with a built-in cooling system and a timed oil filling device (including an independent lubricating oil tank) to control chip accumulation and heat conduction. The design of adding a chip collection basket prevents chips from accumulating or soaking materials at the bottom for a long time, preventing rust and structural damage.
