Aluminum Cutting Cnc Machine

Brand: HUOXIAN
Model:VB-450NS
Type: aluminum cutting cnc machine

Send Inquiry Chat Now

Description

The VB-450NS Aluminum CNC Cutting Machine is a vertical, fully automatic CNC cutting system designed with advanced technology and a precision-oriented engineering concept. It is capable of high-speed, accurate cutting of various aluminum profiles, including round tubes, square tubes, rectangular sections, and solid bars.

Essential information:

Brand: HUOXIAN
Model: VB-450NS
Type: aluminum cutting cnc machine

Product parameters:

	VB-450NS
Cutting Capacity(mm)	Blade diameter: 300; Cutting capacity: 160X60 Blade diameter: 350; Cutting capacity: 230X80 Blade diameter: 400; Cutting capacity: 300X100 Blade diameter: 450; Cutting capacity: 360X130
Voltage(v)	380
Motor Power(kw)	4
Motor Speed(r/min)	3000
Compressed Air(mpa)	0.6---0.8
Single Feeding Stroke(mm)	8-800
Saw Blade(mm)	250-455
Weight(kg)	510
*Machine Size(LWH)(mm)*	1950x1300x1620

Features：

Wide range of processing compatibility
The Aluminum Cutting CNC Machine features a vertical, fully automatic cutting structure, enabling efficient processing of various aluminum profiles, including round tubes, square tubes, rectangular tubes, and solid round bars. It is also compatible with copper materials, meeting customers' diverse material needs.

High feeding accuracy
The equipment is equipped with a high-precision servo feeding system, which controls the feeding error to ±0.1mm. The shortest feeding distance is only 6mm, ensuring stable cutting size and significantly reducing waste of raw materials.

Flexible operation
The cutting equipment supports manual adjustment of sawing speed and is suitable for 250-455mm multi-specification saw blades. It can be quickly adjusted according to different materials and thicknesses to improve processing efficiency and adaptability.

Safety protection
Our equipment adopts a concealed feeding structure to effectively reduce the risk of misoperation, ensure the safety of operators, and improve production safety.
